90-Degree Schedule 40 PVC Side Outlet Elbows

These elbows are used in ventilation system ductwork, plastic fan installations, and industrial air handling systems. Their 90-degree geometry changes airflow direction while the side outlet supports branching or connecting another duct path. Selection should account for the duct layout, connection requirements, operating environment, and compatibility with the surrounding PVC or CPVC system.

The product information identifies both PVC and CPVC as construction material options. The appropriate material should be selected according to the chemical environment, temperature conditions, and compatibility requirements of the ventilation system. IPF Colasit provides thermoplastic ventilation products for harsh, chemical-laden gas streams and can assist with product selection.

The listed fittings use socket-end connections. Socket connections are designed to receive compatible duct or pipe ends and are commonly integrated into thermoplastic ventilation assemblies. Confirm the required size, joining method, and compatibility with the existing system before ordering. Custom size reducers are available upon request when the layout requires a transition.

The product information lists multiple size configurations from 4 inches to 24 inches for the PVC and CPVC fitting range. The required size depends on the connected ductwork, airflow design, and system layout. Contact IPF Colasit with the system dimensions and connection details to identify the appropriate configuration.

Custom size reducers are available upon request. Reducers can help connect ductwork or components with different nominal sizes within a ventilation assembly. Provide the relevant inlet and outlet sizes, material preference, connection details, and application information so the required configuration can be reviewed accurately.

Begin by confirming the required bend angle, outlet arrangement, nominal size, connection type, and material compatibility. For this category, the defining characteristics are a 90-degree bend, Schedule 40 PVC designation, side outlet, and socket-end connections. Also review the chemical environment and air handling application to determine whether PVC or CPVC is appropriate.
